Table 6:
Output Port Where at the RTC6 PCIe Board
1 12-bit analog output port
1
LASER Connector, page 73, ANALOG OUT1
See Figure 17.
2 12-bit analog output port
2
LASER Connector, page 73, ANALOG OUT2
See Figure 17.
MARKING ON THE FLY Socket Connector, page 82,
ANALOG OUT2
See Figure 25.
3 8-bit digital output port EXTENSION 2 Socket Connector, page 80
See Figure 24.
4 16-bit digital output port EXTENSION 1 Socket Connector, page 78
See Figure 22.
5
(a)(b)
(a) Port = 5 cannot be combined with Mode = 0.
(b) Port = 5 cannot be combined with Mode = 256.
Pulse length LASER Connector, page 73, LASER1
See Figure 17.
