RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
504
Result
(cont’d)
10 Only if
Name
= NULL: Param error: HeadNo or ListPos invalid.
11 PCI error during download (get_last_error return code
RTC6_SEND_ERROR
).
13 The specified table number could not be found in the file.
Comments • For information on command usage, see Section ”Jump-Length-Dependent
Jump Delays”, page 218.
• See also Chapter 8.1.5 ”Jump Mode”, page 217.
• Format requirements for placing the table with Jump Delay data points into the text
file are described in Section ”Notes on Loading Determined Jump Delay Values”,
page 219. When loading the table, the RTC6 uses linear interpolation to establish
appropriate values for the complete jump length range.
• load_jump_table_offset overwrites any previously loaded Jump Delay tables for
Jump Mode.
• If
Name
= filename, then the table number
No
is loaded. The other parameters are not
used.
• If
Name
= NULL, then the Jump Delay table for head
No
is automatically determined and
loaded (if Jump Mode has been previously enabled and activated successfully by
set_jump_mode (
Flag
= 1)). Here, the parameters
PosAck
,
Offset
,
MinDelay
,
MaxDelay
and
ListPos
are used (see Section ”Automatic Determination of the Jump Delay Table”,
page 221).
• Jump Mode takes effect upon the next 2D jump only if it has been activated and
enabled by set_jump_mode or activated by set_jump_mode_list.
• load_jump_table_offset is not executed (get_last_error return code
RTC6_BUSY
), if:
– the BUSY list execution status is set
– the INTERNAL-BUSY list execution status is set
• load_jump_table_offset is even executed, if:
– a list has been paused by set_wait (PAUSED list execution status set)
• During the runtime of load_jump_table_offset, External Starts are suppressed.
• Before loading a table, load_jump_table_offset performs a DSP memory check that
produces error code 4 in case of error.
• The table can be saved by create_dat_file.
RTC4RTC6 New command.
There is no RTC4 Compatibility Mode for this command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL
600, OUT 600
, RBF 600.
Reference load_jump_table, set_jump_mode, set_jump_mode_list, get_jump_table,
set_jump_table, create_dat_file
Ctrl Command load_jump_table_offset
