Normal List
Command
mark_date
Function Marks a part of the date previously stored by time_fix, time_fix_f or time_fix_f_off in the
selected format at the current position.
Call mark_date( Part, Mode )
Parameters Part Specifies which part of the date should be marked.
= 0: Year (only the last two digits).
= 1: Month (in customer specific notation).
= 2: Day (corresponding to the normal Gregorian date).
= 3: Day-of-the-week (in customer specific notation).
= 4: Julian day (see also time_fix_f_off).
= 5: Year (4 digits).
= 6: Month as numerals (January = 1,…).
= 7: Day-of-the-week as numerals (Sunday = 1,…).
As an unsigned 32-bit value.
Allowed value range: [0…7].
Mode Selection of the format.
As an unsigned 32-bit value.
Allowed value range: [0…3].
a) Only affects Part = 2, 4, 6 or 7:
The number of leading zeros in the day number.
Bit #0 = 0: Leading zeros are suppressed.
Bit #0 = 1: Day of the month ( Part = 2), always two digits.
Day of the year ( Part = 4), always three digits.
Month ( Part = 6), always two digits.
Day-of-the-week ( Part = 7), always two digits.
b) Only affects Part = 0, 2 or 4…7:
Desired character set for marking digits.
Bit #1 = 0: The indexed text string for digits [0…9], as defined by
load_text_table or set_text_table_pointer, is marked.
Bit #1 = 1: The indexed characters for digits [0…9], as defined by
load_char or set_char_pointer, are marked. The desired
character set can be specified with select_char_set.
For Part = 1 or 3, days of the month or days of the week are marked by
indexed text strings (Index = 10…28) defined with load_text_table or
set_text_table_pointer (here, the parameter Mode is ignored). For marking as
numerals, also Part = 6 or 7 can be used (then Mode is considered).
