Comments • Up to DLL 613, OUT 613 the following applies for HeadNo = 4:
– The global coordinate transformations are only available during a
Processing-on-the-fly Session that has been started by set_fly_2d.
– at_once is ignored
• As of DLL 614, OUT 614 the following applies for HeadNo = 4:
– The global coordinate transformations are generally available, even outside a
Processing-on-the-fly Session.
– Coordinate transformations that have been merely saved, are applied at the next
Processing-on-the-fly Session start.
RTC4RTC6 Unchanged first functionality (transformation matrix definition), however:
• The parameters HeadNo and at_once are new.
• Reduced value range for coefficients.
• See also Section ”Notes for RTC4 Users”, page 227.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
Last change DLL 614, OUT 614: HeadNo = 4 generally available.
References set_matrix_list, set_angle, set_offset, set_scale
Ctrl Command set_matrix
