10 RTC6 Commands
740
innovators for industry
Comments
(cont’d)
• When set_sky_writing_para is called and no list is running or a list has been halted by
set_wait, the following applies:
– With Timelag  1/8, Sky Writing Mode 1 is activated, if Sky Writing has not been
active before. Sky Writing Mode 2 or Sky Writing Mode 3 remain, but the next
Mark Command is always started in Sky Writing Mode 1
– With Timelag < 1/8, Sky Writing is deactivated.
• When set_sky_writing_para is called and a list is running or a list has been halted by
pause_list, the following applies:
– If Sky Writing Mode 2 or Sky Writing Mode 3 is active, then set_sky_writing_para is
not executed (get_last_error return code RTC6_BUSY )
– If no Sky Writing or Sky Writing Mode 0 or Sky Writing Mode 1 is active,
set_sky_writing_para parameters are going to be effective upon the next
list command.
• In Sky Writing Mode 1, an already started Mark Command is executed with the
previous parameters and ended with Sky Writing Mode 1.
• In Sky Writing Mode 0 or Sky Writing Mode 1, the next Mark Command is started
in Sky Writing Mode 1, if Timelag  1/8. Otherwise, it is terminated and a
Mark Delay is inserted in Sky Writing Mode 1.
• For Sky Writing Mode 2 or Sky Writing Mode 3, Nprev = 0 and/or Npost = 0
automatically get(s) internally corrected to 1 (this is not treated as an error). If you
subsequently activate Sky Writing Mode 1 (by set_sky_writing_mode), then
Nprev = 0 and/or Npost = 0 is/are reused.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
In RTC5 Compatibility Mode, the RTC6 multiplies the value specified for LaserOnShift by
32. The allowed value range decreases accordingly.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_sky_writing, set_sky_writing_para_list
Ctrl Command set_sky
_writing_para
