RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
763
Comments
(cont’d)
• For
Ctrl
= 7, the focus shift is linearly varied as with set_defocus and
set_defocus_list, see comments there) with [*]para[*] Commands (in order for the
z outputs to be outputted, the Option “3D” must be enabled and a 3D correction file
must be loaded and assigned as well) up to the specified end value (this requires
enabling the Option “3D” as well as loading and assigning a 3D correction file). If, for
the first [*]para[*] Command, the currently set focus shift does not match the initial
value (
Value)
specified by set_vector_control, then the command begins with a
“Hard Jump” (in the z output) to
Value
. The setting defined by set_defocus or
set_defocus_list is lost.
Unlike signed values in the range [–524,288…+524,287] for set_defocus and
set_defocus_list, the focus shift (
Value
) specified for set_vector_control must be an
unsigned number shifted upward by 524,288:
Value
= focus shift + 524,288.
• “Automatic Laser Control“ should not be combined with the variable laser power of
set_multi_mcbsp_in or the “freely definable wobbel shape”.
RTC4RTC6 New command.
This command has no RTC4 Compatibility Mode for
Value
.
In RTC4 Compatibility Mode, the RTC6 multiplies with
Ctrl
= 7 the specified value for
Value
by 16 (
Value
= focus shift + 32,768).
The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality.
In RTC5 Compatibility Mode, the RTC6 multiplies with
Ctrl
= 7 the specified value for
Value
by 16 (
Value
= focus shift + 32,768).
The allowed value range decreases accordingly.
Version info Available as of DLL 600, OUT 600, RBF 600.
Last change DLL 634:
Ctrl
= 8.
References set_auto_laser_control
Undelayed
Short List
Command
set_vector_control
