Comments
(cont’d)
• For identical amplitudes ( Longitudinal = Transversal ), the wobbel startpoint is
permanently referenced to the coordinate system, that is, independent of the current
direction of motion. By set_wobbel_direction, a fixed reference direction can be set
which differs from it.
• For an angle, ellipse-shaped wobbel movements can result in more or less small jumps
after reaching the corner, depending on the current wobbel phase. This does not occur
(= “rounded corners”) if the wobbel motion is exactly circular
( Longitudinal = Transversal ).
• Longitudinal = 0 produces a sine-shaped wobbel motion across the direction of
movement.
• When defining the wobbel shape and its frequency take the dynamics of the scan head
and laser into account. Otherwise, an overheating and even a permanent damage of
the system may occur, see Chapter 8.4.1 ”Wobbel Shapes – Important Notes on
Choosing Appropriate Parameter Values”, page 234.
• The present wobbel amplitude can be recorded by
set_trigger/set_trigger4/set_trigger8 (signal 53). The format of the data is
((transversal << 16) + longitudinal).
RTC4RTC6 Basically unchanged functionality.
More wobbel shape: elliptical, direction dependent adjustable, see also
set_wobbel_mode.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified value for Longitudinal and
Transversal by 16. The allowed value ranges decrease accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_mark_speed, set_wobbel_mode, set_wobbel_direction
Delayed Short
List Command
set_wobbel
