Comments
(cont’d)
• The present wobbel amplitude can be recorded by
set_trigger/set_trigger4/set_trigger8 (signal 53). The format of the data is
((transversal << 16) + longitudinal).
• The Wobbel Mode cannot be combined with:
– Sky Writing
– Pixel Output Mode
– Jumps
– laser_on_list
RTC4RTC6 New command.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified value for Longitudinal and
Transversal by 16. The allowed value ranges decrease accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_wobbel, set_wobbel_control, set_wobbel_offset, set_wobbel_vector
Delayed Short
List Command
set_wobbel_mode
