Interrupts and events RM0008
132/690
8.3.5 Software interrupt event register (EXTI_SWIER)
Address offset: 0x10
Reset value: 0x0000 0000
8.3.6 Pending register (EXTI_PR)
Address offset: 0x14
Reset value: 0xxxxx xxxx
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
SWIER
18
SWIER
17
SWIER
16
Res. rw rw rw
1514131211109 8765432 1 0
SWIER
15
SWIER
14
SWIER
13
SWIER
12
SWIER
11
SWIER
10
SWIER
9
SWIER
8
SWIER
7
SWIER
6
SWIER
5
SWIER
4
SWIER
3
SWIER
2
SWIER
1
SWIER
0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:19 Reserved, must be kept at reset value (0).
Bits 18:0 SWIERx: Software Interrupt on line x
Writing a 1 to this bit when it is at 0 sets the corresponding pending bit in EXTI_PR. If the interrupt is
enabled on this line on the EXTI_IMR and EXTI_EMR, an interrupt request is generated.
This bit is cleared by clearing the corresponding bit of EXTI_PR (by writing a 1 into the bit).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved PR18 PR17 PR16
Res. rc_w1 rc_w1 rc_w1
1514131211109 8765432 1 0
PR15 PR14 PR13 PR12 PR11 PR10 PR9 PR8 PR7 PR6 PR5 PR4 PR3 PR2 PR1 PR0
rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1
Bits 31:19 Reserved, must be kept at reset value (0).
Bits 18:0 PRx: Pending bit
0: No trigger request occurred
1: selected trigger request occurred
This bit is set when the selected edge event arrives on the external interrupt line. This bit is cleared
by writing a 1 into the bit or by changing the sensitivity of the edge detector.
