RM0008 Real-time clock (RTC)

353/690

15.4.7 RTC register map

RTC registers are mapped as 16-bit addressable registers as described in the table below:

Refer to Table 1 on page 36 for the register boundary addresses.

Table 62.

RTC - register map and reset values

Offset Register

0x000

RTC_CRH

Reserved

OWIE

ALRIE

SECIE

Reset value 000

0x004

RTC_CRL

Reserved

RTOFF

CNF

RSF

OWF

ALRF

SECF

Reset value 100000

0x008

RTC_PRLH

Reserved

PRL[19:16]

Reset value 0000

0x00C

RTC_PRLL

Reserved

PRL[15:0]

Reset value 1000000000000000

0x010

RTC_DIVH

Reserved

DIV[31:16]

Reset value 0000000000000000

0x014

RTC_DIVL

Reserved

DIV[15:0]

Reset value 1000000000000000

0x018 RTC_CNTH

Reserved

CNT[13:16]

Reset value 0000000000000000

0x01C

RTC_CNTL

Reserved

CNT[15:0]

Reset value 0000000000000000

0x020

RTC_ALRH

Reserved

ALR[31:16]

Reset value 1111111111111111

0x024

RTC_ALRL

Reserved

ALR[15:0]

Reset value 1111111111111111
