5.4.5 BKP register map
BKP registers are mapped as 16-bit addressable registers as described in the table below:
Table 13. BKP - register map and reset values
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1 0
0x00 Reserved
0x04
BKP_DR1
Reserved
D[15:0]
Reset value 0000000000000000
0x08
BKP_DR2
Reserved
D[15:0]
Reset value 0000000000000000
0x0C
BKP_DR3
Reserved
D[15:0]
Reset value 0000000000000000
0x10
BKP_DR4
Reserved
D[15:0]
Reset value 0000000000000000
0x14
BKP_DR5
Reserved
D[15:0]
Reset value 0000000000000000
0x18
BKP_DR6
Reserved
D[15:0]
Reset value 0000000000000000
0x1C
BKP_DR7
Reserved
D[15:0]
Reset value 0000000000000000
0x20
BKP_DR8
Reserved
D[15:0]
Reset value 0000000000000000
0x24
BKP_DR9
Reserved
D[15:0]
Reset value 0000000000000000
0x28
BKP_DR10
Reserved
D[15:0]
Reset value 0000000000000000
0x2
BKP_RTCCR
Reserved
ASOS ASOE
CCO
CAL[6:0]
Reset value 0000000000
0x30
BKP_CR
Reserved
TPAL
TPE
Reset value 00
0x34
BKP_CSR
Reserved
TIF
TEF
Reserved
TPIE
CTI
CTE
Reset value 00 000
0x38
Reserved
0x3C
Reserved
0x40
BKP_DR11
Reserved
D[15:0]
Reset value 0000000000000000
