RM0008 Reset and clock control (RCC)
83/690
6.3.4 APB2 peripheral reset register (RCC_APB2RSTR)
Address offset: 0x0C
Reset value: 0x00000 0000
Access: no wait state, word, half-word and byte access
Bit 2 HSIRDYF HSI ready interrupt flag
Reset by software by writing HSIRDYC.
Set by hardware when the Internal High Speed clock becomes stable and HSIRDYDIE is set.
0: No clock ready interrupt caused by the internal 8 MHz RC oscillator
1: Clock ready interrupt caused by the internal 8 MHz RC oscillator
Bit 1 LSERDYF LSE ready interrupt flag
Reset by software by writing LSERDYC.
Set by hardware when the External Low Speed clock becomes stable and LSERDYDIE is set.
0: No clock ready interrupt caused by the external 32 kHz oscillator
1: Clock ready interrupt caused by the external 32 kHz oscillator
Bit 0 LSIRDYF LSI ready interrupt flag
Reset by software by writing LSIRDYC.
Set by hardware when Internal Low Speed clock becomes stable and LSIRDYDIE is set.
0: No clock ready interrupt caused by the internal RC 40 kHz oscillator
1: Clock ready interrupt caused by the internal RC 40 kHz oscillator
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
1514131211109 876543210
ADC3
RST
USART1
RST
TIM8
RST
SPI1
RST
TIM1
RST
ADC2
RST
ADC1
RST
IOPG
RST
IOPF
RST
IOPE
RST
IOPD
RST
IOPC
RST
IOPB
RST
IOPA
RST
Res.
AFIO
RST
rw rw rw rw rw rw rw rw rw rw rw rw rw rw Res. rw
Bits 31:16 Reserved, always read as 0.
Bit 15 ADC3RST ADC3 interface reset
Set and reset by software.
0: No effect
1: Reset ADC3 interface
Bit 14 USART1RST USART1 reset
Set and reset by software.
0: No effect
1: Reset USART1
Bit 13 TIM8RST TIM8 timer reset
Set and reset by software.
0: No effect
1: Reset TIM8 timer
