Digital-to-analog converter (DAC) RM0008
200/690
11.5.4 DAC channel1 12-bit Left aligned Data Holding Register
(DAC_DHR12L1)
Address offset: 0x0C
Reset value: 0x0000 0000
11.5.5 DAC channel1 8-bit Right aligned Data Holding Register
(DAC_DHR8R1)
Address offset: 0x10
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DACC1DHR[11:0] Reserved
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 Reserved.
Bit 15:4 DACC1DHR[11:0]: DAC channel1 12-bit Left aligned data
These bits are written by software which specify 12-bit data for DAC channel1.
Bits 3:0 Reserved.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved DACC1DHR[7:0]
rw rw rw rw rw rw rw rw
Bits 31:8 Reserved.
Bits 7:0 DACC1DHR[7:0]: DAC channel1 8-bit Right aligned data
These bits are written by software which specify 8-bit data for DAC channel1.
