RM0008 Independent watchdog (IWDG)

359/690

16.4.5 IWDG register map

The following table gives the IWDG register map and reset values.

Refer to Table 1 on page 36 for the register boundary addresses.

Table 64. IWDG register map and reset values

Offset Register

0x00

IWDG_KR

Reserved

KEY[15:0]

Reset value 0000000000000000

0x04

IWDG_PR

Reserved

PR[2:0]

Reset value 000

0x08

IWDG_RLR

Reserved

RL[11:0]

Reset value 111111111111

0x0C

IWDG_SR

Reserved

RVU

PVU

Reset value 00
