Flexible static memory controller (FSMC) RM0008
392/690
Table 93. FSMC_BCRx bit fields
Bit No. Bit name Value to set
31-20 0x0000
19 CBURSTRW 0x1
18-15 0x0
14 EXTMOD 0x0
13 WAITEN
When high, the first data after latency period is taken as always
valid, regardless of the wait from memory value
12 WREN no effect on synchronous read
11 WAITCFG 0x0
10 WRAPMOD to be set according to memory
9 WAITPOL to be set according to memory
8 BURSTEN no effect on synchronous write
7 FWPRLVL Set to protect memory from accidental writes
6 FACCEN Set according to memory support
5-4 MWID As needed
3-2 MTYP 01 or 11
1 MUXEN As needed
0 MBKEN 0x1
Table 94. FSMC_TCRx bit fields
Bit No. Bit name Value to set
31-30 - 0x0
27-24 DATLAT Data latency
23-20 CLKDIV
0 to get CLK = HCLK (not supported)
1 to get CLK = 2 × HCLK
19-16 BUSTURN No effect
15-8 DATAST No effect
7-4 ADDHLD No effect
3-0 ADDSET No effect
