ST STM32F102 series User Manual

RM0008 Digital-to-analog converter (DAC)
201/690
11.5.6 DAC channel2 12-bit Right aligned Data Holding Register
(DAC_DHR12R2)
Address offset: 0x14
Reset value: 0x0000 0000
11.5.7 DAC channel2 12-bit Left aligned Data Holding Register
(DAC_DHR12L2)
Address offset: 0x18
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved DACC2DHR[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:12 Reserved.
Bits 11:0
DACC2DHR[11:0]: DAC channel2 12-bit Right aligned data
These bits are written by software which specify 12-bit data for DAC channel2.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DACC2DHR[11:0] Reserved
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 Reserved.
Bits 15:4 DACC2DHR[11:0]: DAC channel2 12-bit Left aligned data
These bits are written by software which specify 12-bit data for DAC channel2.
Bits 3:0 Reserved.

ST STM32F102 series Specifications

General

Series	STM32F102
Core	ARM Cortex-M3
Operating Voltage	2.0 V to 3.6 V
Operating Temperature	-40°C to +85°C
SRAM	4 KB to 8 KB
ADC	12-bit
Communication Interfaces	USART, SPI, I2C
Package	LQFP
