Flexible static memory controller (FSMC) RM0008
390/690
11 WAITCFG to be set according to memory
10 WRAPMOD to be set according to memory
9 WAITPOL to be set according to memory
8 BURSTEN 0x1
7 FWPRLVL Set to protect memory from accidental write access
6 FACCEN Set according to memory support
5-4 MWID As needed
3-2 MTYP As needed
1 MUXEN As needed
0 MBKEN 0x1
Table 92. FSMC_TCRx bit fields
Bit No. Bit name Value to set
27-24 DATLAT Data latency
23-20 CLKDIV
0 to get CLK = HCLK (not supported)
1 to get CLK = 2 × HCLK
19-16 BUSTURN no effect
15-8 DATAST no effect
7-4 ADDHLD no effect
3-0 ADDSET no effect
Table 91. FSMC_BCRx bit fields (continued)
Bit No. Bit name Value to set
