RM0008 Digital-to-analog converter (DAC)
199/690
11.5.2 DAC Software Trigger Register (DAC_SWTRIGR)
Address offset: 0x04
Reset value: 0x0000 0000
11.5.3 DAC channel1 12-bit Right-aligned Data Holding Register
(DAC_DHR12R1)
Address offset: 0x08
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
1514131211109876543210
Reserved
SWTRI
G2
SWTRI
G1
ww
Bits 31:2 Reserved.
Bit 1 SWTRIG2: DAC channel2 software trigger
This bit is set and cleared by software to enable/disable the software trigger.
0: Software trigger disabled
1: Software trigger enabled
Note: This bit is reset by hardware (one APB1 clock cycle later) once the DAC_DHR2 register value
is loaded to the DAC_DOR2 register.
Bit 0 SWTRIG1: DAC channel1 software trigger
This bit is set and cleared by software to enable/disable the software trigger.
0: Software trigger disabled
1: Software trigger enabled
Note: This bit is reset by hardware (one APB1 clock cycle later) once the DAC_DHR1 register value
is loaded to the DAC_DOR1 register.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved DACC1DHR[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:12 Reserved.
Bit 11:0 DACC1DHR[11:0]: DAC channel1 12-bit Right aligned data
These bits are written by software which specify 12-bit data for DAC channel1.
