Digital-to-analog converter (DAC) RM0008
202/690
11.5.8 DAC channel2 8-bit Right-aligned Data Holding Register
(DAC_DHR8R2)
Address offset: 0x1C
Reset value: 0x0000 0000
11.5.9 Dual DAC 12-bit Right-aligned Data Holding Register
(DAC_DHR12RD)
Address offset: 0x20
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved DACC2DHR[7:0]
rw rw rw rw rw rw rw rw
Bits 31:8 Reserved.
Bits 7:0 DACC2DHR[7:0]: DAC channel2 8-bit Right aligned data
These bits are written by software which specify 8-bit data for DAC channel2.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved DACC2DHR[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved DACC1DHR[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:28 Reserved.
Bits 27:16
DACC2DHR[11:0]: DAC channel2 12-bit Right aligned data
These bits are written by software which specify 12-bit data for DAC channel2.
Bits 15:12 Reserved.
Bits 11:0
DACC1DHR[11:0]: DAC channel1 12-bit Right aligned data
These bits are written by software which specify 12-bit data for DAC channel1.
