Digital-to-analog converter (DAC) RM0008
196/690
11.5 DAC registers
11.5.1 DAC control register (DAC_CR)
Address offset: 0x00
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
DMA
EN2
MAMP2[3:0] WAVE2[1:0] TSEL2[2:0] TEN2 BOFF2 EN2
rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
Reserved
DMA
EN1
MAMP1[3:0] WAVE1[1:0] TSEL1[2:0] TEN1 BOFF1 EN1
rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:29 Reserved.
Bit 28 DMAEN2: DAC channel2 DMA enable
This bit is set and cleared by software.
0: DAC channel2 DMA mode disabled
1: DAC channel2 DMA mode enabled
Bit 27:24 MAMP2[3:0]: DAC channel2 Mask/Amplitude selector
These bits are written by software to select mask in wave generation mode or amplitude in triangle
generation mode.
0000: Unmask bit0 of LFSR/ Triangle Amplitude equal to 1
0001: Unmask bits[1:0] of LFSR/ Triangle Amplitude equal to 3
0010: Unmask bits[2:0] of LFSR/ Triangle Amplitude equal to 7
0011: Unmask bits[3:0] of LFSR/ Triangle Amplitude equal to 15
0100: Unmask bits[4:0] of LFSR/ Triangle Amplitude equal to 31
0101: Unmask bits[5:0] of LFSR/ Triangle Amplitude equal to 63
0110: Unmask bits[6:0] of LFSR/ Triangle Amplitude equal to 127
0111: Unmask bits[7:0] of LFSR/ Triangle Amplitude equal to 255
1000: Unmask bits[8:0] of LFSR/ Triangle Amplitude equal to 511
1001: Unmask bits[9:0] of LFSR/ Triangle Amplitude equal to 1023
1010: Unmask bits[10:0] of LFSR/ Triangle Amplitude equal to 2047
≥ 1011: Unmask bits[11:0] of LFSR/ Triangle Amplitude equal to 4095
Bit 23:22 WAVE2[1:0]: DAC channel2 noise/triangle wave generation enable
These bits are set/reset by software.
00: wave generation disabled
01: Noise wave generation enabled
1x: Triangle wave generation enabled
Note: only used if bit TEN2 = 1 (DAC channel2 trigger enabled)
