RM0008 Analog-to-digital converter (ADC)
169/690
10.12 ADC registers
Refer to Section 1.1 on page 32 for a list of abbreviations used in register descriptions.
10.12.1 ADC status register (ADC_SR)
Address offset: 0x00
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved STRT JSTRT JEOC EOC AWD
Res. rc_w0 rc_w0 rc_w0 rc_w0 rc_w0
Bits 31:5 Reserved, must be kept cleared.
Bit 4 STRT: Regular channel Start flag
This bit is set by hardware when regular channel conversion starts. It is cleared by software.
0: No regular channel conversion started
1: Regular channel conversion has started
Bit 3 JSTRT: Injected channel Start flag
This bit is set by hardware when injected channel group conversion starts. It is cleared by software.
0: No injected group conversion started
1: Injected group conversion has started
Bit 2 JEOC: Injected channel end of conversion
This bit is set by hardware at the end of all injected group channel conversion. It is cleared by
software.
0: Conversion is not complete
1: Conversion complete
Bit 1 EOC: End of conversion
This bit is set by hardware at the end of a group channel conversion (regular or injected). It is
cleared by software or by reading the ADC_DR.
0: Conversion is not complete
1: Conversion complete
Bit 0 AWD: Analog watchdog flag
This bit is set by hardware when the converted voltage crosses the values programmed in the
ADC_LTR and ADC_HTR registers. It is cleared by software.
0: No Analog Watchdog event occurred
1: Analog Watchdog event occurred
