Digital-to-analog converter (DAC) RM0008
204/690
11.5.12 DAC channel1 Data Output Register (DAC_DOR1)
Address offset: 0x2C
Reset value: 0x0000 0000
11.5.13 DAC channel2 Data Output Register (DAC_DOR2)
Address offset: 0x30
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved DACC1DOR[11:0]
rrrrrrrrrrrr
Bits 31:12 Reserved.
Bit 11:0
DACC1DOR[11:0]: DAC channel1 data output
These bits are read only, they contain data output for DAC channel1.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved DACC2DOR[11:0]
rrrrrrrrrrrr
Bits 31:12 Reserved.
Bit 11:0
DACC2DOR[11:0]: DAC channel2 data output
These bits are read only, they contain data output for DAC channel2.
