Bit 6 DTOG_TX: Data Toggle, for transmission transfers
If the endpoint is non-isochronous, this bit contains the required value of the data toggle bit
(0=DATA0, 1=DATA1) for the next data packet to be transmitted. Hardware toggles this bit when the
ACK handshake is received from the USB host, following a data packet transmission. If the endpoint
is defined as a control one, hardware sets this bit to 1 at the reception of a SETUP PID addressed to
this endpoint.
If the endpoint is using the double buffer feature, this bit is used to support packet buffer swapping
too (Refer to Section 20.4.3: Double-buffered endpoints)
If the endpoint is Isochronous, this bit is used to support packet buffer swapping since no data
toggling is used for this sort of endpoints and only DATA0 packet are transmitted (Refer to
Section 20.4.4: Isochronous transfers). Hardware toggles this bit just after the end of data packet
transmission, since no handshake is used for Isochronous transfers.
This bit can also be toggled by the software to initialize its value (mandatory when the endpoint is
not a control one) or to force a specific data toggle/packet buffer usage. When the application
software writes ‘0’, the value of DTOG_TX remains unchanged, while writing ‘1’ makes the bit value
toggle. This bit is read/write but it can only be toggled by writing 1.
Bits 5:4 STAT_TX [1:0]: Status bits, for transmission transfers
These bits contain the information about the endpoint status, listed in Ta ble 1 4 0. These bits can be
toggled by the software to initialize their value. When the application software writes ‘0’, the value
remains unchanged, while writing ‘1’ makes the bit value toggle. Hardware sets the STAT_TX bits to
NAK, when a correct transfer has occurred (CTR_TX=1) corresponding to a IN or SETUP (control
only) transaction addressed to this endpoint. It then waits for the software to prepare the next set of
data to be transmitted.
Double-buffered bulk endpoints implement a special transaction flow control, which controls the
status based on buffer availability condition (Refer to Section 20.4.3: Double-buffered endpoints).
If the endpoint is defined as Isochronous, its status can only be “VALID” or “DISABLED”. Therefore,
the hardware cannot change the status of the endpoint after a successful transaction. If the software
sets the STAT_TX bits to ‘STALL’ or ‘NAK’ for an Isochronous endpoint, the USB peripheral behavior
is not defined. These bits are read/write but they can be only toggled by writing ‘1’.
Bits 3:0 EA[3:0]: Endpoint Address.
Software must write in this field the 4-bit address used to identify the transactions directed to this
endpoint. A value must be written before enabling the corresponding endpoint.
Table 137. Reception status encoding
STAT_RX[1:0] Meaning
00 DISABLED: all reception requests addressed to this endpoint are ignored.
01
STALL: the endpoint is stalled and all reception requests result in a STALL
handshake.
10 NAK: the endpoint is naked and all reception requests result in a NAK handshake.
11 VALID: this endpoint is enabled for reception.
Table 138. Endpoint type encoding
EP_TYPE[1:0] Meaning
00 BULK
01 CONTROL
10 ISO
11 INTERRUPT
