ST STM32F102 series User Manual

RM0008 DMA controller (DMA)
147/690
0x024
DMA_CPAR2 PA[31:0]
Reset value 00000000000000000000000000000000
0x028
DMA_CMAR2 MA[31:0]
Reset value 00000000000000000000000000000000
0x02C Reserved
0x030
DMA_CCR3
Reserved
MEM2MEM
PL
[1:0]
M
SIZE
[1:0]
PSIZE
[1:0]
MINC
PINC
CIRC
DIR
TEIE
HTIE TCIE
EN
Reset value 000000000000000
0x034
DMA_CNDTR3
Reserved
NDT[15:0]
Reset value 0000000000000000
0x038
DMA_CPAR3 PA[31:0]
Reset value 00000000000000000000000000000000
0x03C
DMA_CMAR3 MA[31:0]
Reset value 00000000000000000000000000000000
0x040 Reserved
0x044
DMA_CCR4
Reserved
MEM2MEM
PL
[1:0]
M
SIZE
[1:0]
PSIZE
[1:0]
MINC
PINC
CIRC
DIR
TEIE
HTIE TCIE
EN
Reset value 000000000000000
0x048
DMA_CNDTR4
Reserved
NDT[15:0]
Reset value 0000000000000000
0x04C
DMA_CPAR4 PA[31:0]
Reset value 00000000000000000000000000000000
0x050
DMA_CMAR4 MA[31:0]
Reset value 00000000000000000000000000000000
0x054 Reserved
0x058
DMA_CCR5
Reserved
MEM2MEM
PL
[1:0]
M
SIZE
[1:0]
PSIZE
[1:0]
MINC
PINC
CIRC
DIR
TEIE
HTIE TCIE
EN
Reset value 000000000000000
0x05C
DMA_CNDTR5
Reserved
NDT[15:0]
Reset value 0000000000000000
0x060
DMA_CPAR5 PA[31:0]
Reset value 00000000000000000000000000000000
0x064
DMA_CMAR5 MA[31:0]
Reset value 00000000000000000000000000000000
0x068 Reserved
Table 41. DMA - register map and reset values (continued)
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1 0
