RM0008 Flexible static memory controller (FSMC)

409/690

Attribute memory space timing registers 2..4 (FSMC_PATT2..4)

Address offset: 0xA000 0000 + 0x4C + 0x20 * (x – 1), x = 2..4

Reset value: 0xFCFC FCFC

Each FSMC_PATTx (x = 2..4) read/write register contains the timing information for PC Card

or NAND Flash memory bank x, used for access to the attribute memory space of the 16-bit

PC Card/CompactFlash, or to access the NAND Flash for last address write access if timing

must differ from the other accesses (for Ready/Busy management, refer to Section 18.6.4:

NAND-Flash ready/busy management).

313029282726252423222120191817161514131211109876543210

ATTHIZx ATTHOLDx ATTWAITx ATTSETx

r/w r/w r/w r/w

Bits 31:24 ATTHIZx: Attribute memory x databus HiZ time.

Defines the number of HCLK clock cycles during which the databus is kept in HiZ after the start of a

PC CARD/NAND Flash write access to attribute memory space on socket x. Only valid for write

transaction:

0000 0000: 0 HCLK cycle

1111 1111: 255 HCLK cycles (default value after reset)

Bits 23:16 ATTHOLDx: Attribute memory x hold time.

Defines the number of HCLK (+1) clock cycles to hold address (and data for write access) after the

command deassertion (NWE, NOE), for PC CARD/NAND Flash read or write access to attribute

memory space on socket x

0000 0000: 1 HCLK cycle

1111 1111: 256 HCLK cycles (default value after reset)

Bits 15:8 ATTWAITx: Attribute memory x wait time.

Defines the minimum number of HCLK (+1) clock cycles to assert the command (NWE, NOE), for

PC CARD/NAND Flash read or write access to attribute memory space on socket x. The duration

for command assertion is extended if the wait signal (NWAIT) is active (low) at the end of the

programmed value of HCLK:

0000 0000: 1 HCLK cycle (+ wait cycle introduced by deassertion of NWAIT)

1111 1111: 256 HCLK cycles (+ wait cycle introduced by the card deasserting NWAIT) (default

value after reset)

Bits 7:0 ATTSETx: Attribute memory x setup time.

Defines the number of HCLK (+1) clock cycles to set up address before the command assertion

(NWE, NOE), for PC CARD/NAND Flash read or write access to attribute memory space on socket

0000 0000: 1 HCLK cycle

1111 1111: 256 HCLK cycles (default value after reset)
