ST STM32F102 series User Manual

RM0008 Controller area network (bxCAN)
541/690
0x1B8
CAN_RDL0R DATA3[7:0] DATA2[7:0] DATA1[7:0] DATA0[7:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x1BC
CAN_RDH0R DATA7[7:0] DATA6[7:0] DATA5[7:0] DATA4[7:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x1C0
CAN_RI1R STID[10:0]/EXID[28:18] EXID[17:0]
IDE
RTR
Reserved
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x1C4
CAN_RDT1R TIME[15:0] FMI[7:0]
Reserved
DLC[3:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxx xxxx
0x1C8
CAN_RDL1R DATA3[7:0] DATA2[7:0] DATA1[7:0] DATA0[7:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x1CC
CAN_RDH1R DATA7[7:0] DATA6[7:0] DATA5[7:0] DATA4[7:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x1D0-
0x1FF
Reserved
0x200
CAN_FMR
Reserved
FINIT
Reset value 1
0x204
CAN_FM1R
Reserved
FBM[13:0]
Reset value 00000000000000
0x208
Reserved
0x20C
CAN_FS1R
Reserved
FSC[13:0]
Reset value 00000000000000
0x210
Reserved
0x214
CAN_FFA1R
Reserved
FFA[13:0]
Reset value 00000000000000
0x218
Reserved
0x21C
CAN_FA1R
Reserved
FACT[13:0]
Reset value 00000000000000
0x220
Reserved
0x224-
0x23F
Reserved
0x240
CAN_F0R1 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x244
CAN_F0R2 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
Table 145. bxCAN - register map and reset values (continued)
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1 0
