Device electronic signature RM0008

652/690

Address offset: 0x08

Read only = 0xXXXX XXXX where X is factory-programmed

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

U_ID(95:80)

rrrrrrrrrrrrrrrr

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

U_ID(79:64)

rrrrrrrrrrrrrrrr

Bits 31:0 U_ID(95:64): 95:64 Unique ID bits.
