RM0351 Reset and clock control (RCC)
278
6.4.3 Clock configuration register (RCC_CFGR)
Address offset: 0x08
Reset value: 0x0000 0000
Access: 0 wait state 2, word, half-word and byte access
1 or 2 wait states inserted only if the access occurs during clock source switch.
From 0 to 15 wait states inserted if the access occurs when the APB or AHB prescalers
values update is on going.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. MCOPRE[2:0] MCOSEL[3:0] Res. Res. Res. Res. Res. Res. Res. Res.
rw rw rw rw rw rw rw
1514131211109 8 7 654321 0
STOP
WUCK
Res. PPRE2[2:0] PPRE1[2:0] HPRE[3:0] SWS[1:0] SW[1:0]
rw rw rw rw rw rw rw rw rw rw rw r r rw rw
Bit 31 Reserved, must be kept at reset value.
Bits 30:28 MCOPRE[2:0]: Microcontroller clock output prescaler
These bits are set and cleared by software.
It is highly recommended to change this prescaler before MCO output is enabled.
000: MCO is divided by 1
001: MCO is divided by 2
010: MCO is divided by 4
011: MCO is divided by 8
100: MCO is divided by 16
Others: not allowed
Bits 27:24 MCOSEL[3:0]: Microcontroller clock output (MCOSEL[2:0] only for
STM32L475xx/476xx/486xx devices)
Set and cleared by software.
0000: MCO output disabled, no clock on MCO
0001: SYSCLK system clock selected
0010: MSI clock selected.
0011: HSI16 clock selected.
0100: HSE clock selected
0101: Main PLL clock selected
0110: LSI clock selected
0111: LSE clock selected
1000: Internal HSI48 clock selected (only for STM32L496xx/4A6xx devices)
Others: Reserved
Note: This clock output may have some truncated cycles at startup or during MCO clock
source switching.
Bits 23:16 Reserved, must be kept at reset value.
