Peripherals interconnect matrix RM0351
326/1830 DocID024597 Rev 5
10.3.1 From timer (TIM1/TIM2/TIM3/TIM4/TIM5/TIM8/TIM15/TIM16/TIM17) to
timer (TIM1/TIM2/TIM3/TIM4/TIM5/TIM8/TIM15)
Purpose
Some of the TIMx timers are linked together internally for timer synchronization or chaining.
When one timer is configured in Master Mode, it can reset, start, stop or clock the counter of
another timer configured in Slave Mode.
A description of the feature is provided in: Section 31.3.19: Timer synchronization.
The modes of synchronization are detailed in:
• Section 30.3.26: Timer synchronization for advanced-control timers (TIM1/TIM8)
• Section 31.3.18: Timers and external trigger synchronization for general-purpose
timers (TIM2/TIM3/TIM4/TIM5)
• Section 32.4.17: External trigger synchronization (TIM15 only) for general-purpose
timer (TIM15)
Triggering signals
The output (from Master) is on signal TIMx_TRGO (and TIMx_TRGO2 for TIM1/TIM8)
following a configurable timer event.
The input (to slave) is on signals TIMx_ITR0/ITR1/ITR2/ITR3
The input and output signals for TIM1/TIM8 are shown in Figure 211: Advanced-control
timer block diagram.
The possible master/slave connections are given in:
• Table 187: TIMx internal trigger connection
• Table 192: TIMx internal trigger connection
• Table 195: TIMx Internal trigger connection
EXTI - - - - - - - - - - - - - 2225- - 44- - -
RTC
- - - - - - - - - 7 - 88 - - - - - - - - - - -
COMP1 13 13 13 13
- - - - 13 13 13 8 8 - - - - - - - - - - -
COMP2 13 13 13 13
- - - - 13 13 13 8 8 - - - - - - - - - - -
SYST ERR 14 14
- - - - - - 14 14 14 - - - - - - - - - - - - -
USB
- - 11 - - - - - - - - - - - - - - - - - - - - -
1. Numbers in table are links to corresponding detailed sub-section in Section 10.3: Interconnection details.
2. The “-” symbol in grayed cells means no interconnect.
Table 41. STM32L4x5/STM32L4x6 peripherals interconnect matrix
(1) (2)
(continued)
Source
Destination
TIM1 TIM8 TIM2 TIM3 TIM4 TIM5 TIM6 TIM7 TIM15 TIM16 TIM17 LPTIM1 LPTIM2 ADC1 ADC2 ADC3 DFSDM1 OPAMP1 OPAMP2 DAC1 DAC2 COMP1 COMP2 IRTIM
