TROUBLESHOOTING
Sysmex SF-3000 Operator's Manual -- Revised September 1995 8-73
4 . Sampler CP Mech.
Select this program to execute test operation of the mixing and aspiration mechanism in
the Auto Closed Sampler. Execute this test when one of the following error messages
appears and sample analysis cannot be performed. If the test corrects the error, sampler
analysis can be performed.
"Tube Invert Position Error" "Hand Initial Position Error"
"Hand Move Position Error" "Hand Upper Position Error"
"Hand Lower Position Error" "Set Piercer Cover"
(1) Bring the Test screen by pressing [Mainte.] and then [Test] keypads (Refer to
Section 3.1 in this chapter).
(2) Press the [Sampler CP Mech.] keypad from the Test screen. The message "Press
Start Switch" will appear.
(3) Press the Start Switch. The cap piercer and aspiration mechanism operation will be
executed, and the hand will return to its initial position. Check the operation using
the figure below as a guide.
g
f
d
c
b
a
h
e
Figure 8-17: CP Mechanism Operation
(4) Press [Return] to end the test program.
Sysmex SF-3000 Operator's Manual -- Revised July 1996
