SUPPLEMENT S2
Chapter 27 – Flight Control
CHAPTER 27 – FLIGHT CONTROL
HAND CONTROL REMOVAL (Refer to Figures B-1 and B-2)
1) Remove the LH and RH front fuselage inspection panels and disconnect the cold
air hose;
2) Remove the two MS20004 recessed head bolts that hold the bearing on the
cockpit panel - see fig. B-2;
3) Remove the bolts (marked as "TO BE REMOVED" in the picture B-1) from the
mechanical interface (p/n 22-5-445-000);
4) Disconnect the flap connector and secure it to the central column;
5) Pull out the hand control assembly from the cockpit;
6) Install the cover plate on the instrument panel to hide the hole;
7) Select the flap switch selector on STD. position.
POST-REMOVAL CHECKS
1) Move the rudder pedals and verify the following:
(a) Movement is free and smooth;
(b) The rudder control reaches its maximum travel in both directions;
2) Actuate the throttle control (LH lever) and verify the following:
(a) Movement is free and smooth;
(b) The throttle control reaches its maximum travel in both directions (verify
with the end travel stops of standard plug-type throttle controls)
