SUPPLEMENT SG-3
CHAPTER 31 - INDICATIONG SYSTEM
Page 216
Step
no.
Airspeed Markings setup
Additional info
&References
AIRSPEEDS box is selected.
16.
Set up each required airspeed in accordance with
applicable AFMS section 2
17.
When the correct airspeed value has been entered
press ENT key.
18.
At process completion power down the system and
remove the unlock card from the bottom slot.
19.
Restart the system in normal mode.
Appendix A
Configuration mode allows the technician with a means of configuring,
checking, and calibrating various G500 sub-systems. Troubleshooting/diagnostics
information can also be derived from this mode.
To start the system in Configuration mode:
Step
no.
G500 Configuration mode
Additional info
&References
1.
Master OFF
2.
GDU breaker: pull
3.
GRS breaker: pull
4.
GDC breaker: pull
5.
Insert the correct Installer Unlock Card (010-
00769-60) into the GDU620 bottom card slot
6.
Make sure that SW part number, reported on
the SD Loader Card, is the correct one.
7.
Insert the correct G500 software Loader card
into the GDU620 top card slot
8.
Make sure that GDU620 breaker is pulled
9.
Master switch: ON
10.
GRS breaker: push
11.
GDC breaker: push
12.
While holding the ENT key on the GDU620,
restore power by closing the GDU circuit
breaker
