SUPPLEMENT S2
ENGINE- POST-SHIPMENT REASSEMBLY INSTRUCTION
1
st
Edition - Rev
2. P
OWERPLANT CONTROLS RIGGING
This chapter contains the complete procedure for powerplant controls rigging.
Procedure
Step
no.
Powerplant con-
trol rigging
Task description
Additional
info &
References
1.
Engage parking brake
2.
Open engine cowlings (upper and
lower)
See Chapter 54
of Basic MM
AIR-BOX CONTROL RIGGING
1.
Connect airbox bowden cable to
airbox control lever
2.
Check carburetor heat control
stroke
• Ensure that when
Carb. Heat knob
is full forward
(Off position),
air-box control
lever is fully
rightward (Refer
to Figure 77.1.)
• Ensure that when
Carb. Heat knob
is full backward ,
air-box control
lever is fully
leftward (Refer to
Figure 77.2.)
