Page 203
SUPPLEMENT S2
ENGINE- POST-SHIPMENT REASSEMBLY INSTRUCTION
Step
no.
Powerplant con-
Task description
Additional
info &
References
3.
Stroke adjustment.
• Remove airbox bowden cable
from air-box control lever
• Loosen nut
• Screw/unscrew rod end bearing
to adjust cable as needed
• Screw nut to lock position
• Connect bowden cable to con-
trol lever.
4.
Check carburetor heat control
stroke
CHOKE CONTROL RIGGING
1.
Connect choke bowden cable to
choke control lever
2.
Check choke control stroke
• Ensure that when
choke knob is
fully upward ,
choke control
lever reaches the
relative stop
screw (Refer to
Figure 77.3.)
• Ensure that when
choke knob is
fully downward ,
choke control
lever reaches the
relative stop
screw (Refer to
Figure 77.4.)
