Tecnam P2002 JF - Page 1186

Page 204
SUPPLEMENT S2
ENGINE- POST-SHIPMENT REASSEMBLY INSTRUCTION
1
st
Edition - Rev
Step
no.
Powerplant con-
trol rigging
Task description
Additional
info &
References
3.
Stroke Adjusting
• move choke control cable from
choke control lever loosing nut
• adjust cable as required
• Screw nut to lock position and
apply cable end
4.
Check choke control stroke
THROTTLE CONTROL RIGGING
1.
Connect throttle bowden cable to
throttle control lever
2.
Check throttle control stroke
• Ensure that when
throttle knob is
fully forward ,
throttle control
lever is fully
forward (Refer to
Figure 77.5.)
• Ensure that when
throttle knob is
fully backward ,
throttle control
lever is fully
backward (Refer
to Figure 77.6.)
3.
Stroke adjusting
• move throttle control cable from
throttle control lever loosing nut
• adjust cable as required
• Screw nut to lock position and ap-
ply cable end
4.
Check throttle control stroke
