CABIN INTERIORS – MAINTENANCE PRACTICES’
Panel IP1
Step
Task description
Refer to:
1.
Unscrew and remove from panel
compass
2.
Unscrew the RH two upper screws and
the two LH upper screws of IP01 panel
3.
Unscrew the LH and the RH frontal
lower screws
4.
Pull out IP1 panel
5.
For reassembly panel, reverse these
steps
