Tecnam P2002 JF - Page 372

Page 203 2
nd
Edition – Rev 0
25-10
CABIN INTERIORS – MAINTENANCE PRACTICES’
Panel IP2
Step
Task description
Refer to:
1.
Apply IP1 panel removal procedure
Tab. 1
2.
Slide off IP2 panel from its location
Panel LH1
Step
Task description
Refer to:
1.
Lift, move or remove fitted-carpet in
correspondence of panel lower side
2.
Remove panel pins (A-A’ type)
3.
Pull out LH1 panel from its location
4.
For reassembly panel, reverse these
steps.
