Chapter 61 – Propeller
Page 205
Step
no.
Governor replacement
Task description
Additional info
&References
11.
Clean engine pad, studs and mounting
hardware before installing new mounting
gasket.
Ensure governor drive spline mate correct-
ly with engine accessory drive spline.
12.
Attach mounting hardware and torque the
(4) mounting nuts to 11-15 Nm (93-133 in-
Ibs
13.
Reconnect propeller bowden cable to gov-
ernor control lever:
14.
Install hydraulic connection to accumulator
– mount on governor fitting.
15.
Check correspondence between governor
lever position and propeller knobs.
 Ensure that when pro-
peller knob is full for-
ward, governor control
lever reaches the rela-
tive stop screw
 Ensure that when pro-
peller knob is in full
rwar position governor
control lever reaches
the relative stop screw
16.
Adjusting correspondence.
 remove propeller bowden cable
from governor control lever
 Loosen nut
 Screw/unscrew rod end bearing to
adjust cable as needed
 Screw nut to lock position
 Join Bowden cable.
