FERTILISER DISTRIBUTOR, BREDAL K RAMP TEEJET 5000 OPERATORS MANUAL
4.80
Pressing the “NEXT PAGE” key displays the next functions.
OFFSET
AUGER: Offset increase/decrease.
OFFSET
+XX%: Offset increase (only shown if OFFSET
AUGER is activated).
OFFSET
-XX%: Offset decrease (only shown if OFFSET
AUGER is activated).
RPM
AUGER: Auger speed.
OFFSET
AUGER: Offset ON/OFF. When this key is pressed the OFFSET function is
activated.
OFFSET
+/-XX%: Step increase or decrease. This function is only shown if the
OFFSET function is activated. The size of the offset steps is
encoded in the service menu (see encode). The OFFSET function
is used to alter the standard auger speed. The auger speed is
determined by a curve in relation to the application rate. The auger
speed is altered when the application rate is altered and changing
the OFFSET changes the relation between auger speed and the
application rate.
RPM
AUGER: Pressing this key displays the auger speed in RPM.
Pressing the “NEXT PAGE” key displays the next functions.
MANUAL
START: Manual auger start
EMPTY
AUGER: Emptying the auger.
MANUAL
START: The belt and auger run for 30 seconds when this key is pressed.
The runs at a speed co-responding to a forward speed of 8 kph
and the auger turns with 250 RPM. Manual start is cancelled after
30 seconds or when the forward speed is over 3 kph.
Manual start can, e.g. be used in field corners where a run up is
not possible.
