TEEJET 5000 OPERATORS MANUAL SLURRY SPREADER, OTHER TYPE
7.5
SLURRY SPREADER: WITHOUT FLOWMETER
TON/M3: Slurry consumption in
ton/m3.
RPM 1: Revolutions per minute.
TON/M3: The amount of slurry spread since starting. This function works as
a trip counter, and can be deleted in “DATA/DELETE”. The total
counter is also found here.
RPM 1: The shaft speed of an axle is displayed here. Normally the RPM of
the distributor/macerator.
MANUAL BOOM SECTIONS:
SECTION WIDTH:
When working with 2 boom sections, the boom section
that is encoded as section 2 can be “switched” on or off
by pressing “SECTION WIDTH”. Area measurement and
flow will now be calculated correctly for the section that is
still on.
Conditions for manual section width:
Only 2 sections must be encoded and the part of the
boom to be switched off must be encoded as section 2.
BOOM SECTIONS ON/OFF:
The picture shows that the spreader has 2 sections and
only one is open. The total number of sections must be
encoded in “DISTRIB. WIDTH”.
I
When the override sensor is activated (not measuring
area “I” is displayed.
