Step 4
Place the ground strap cable (see the figure below) on the door and the chassis and tighten the nuts.
Figure 58: Ground Strap Cable — Standard Door
Step 5
Tighten the door screws to a torque value of 6.5 in-lb (0.75 N-m) to close the standard door as shown in the
figure below.
Figure 59: Close the Standard Door of NCS 2002 Shelf
Stop. You have completed this procedure.
Cisco NCS 2000 Series Hardware Installation Guide
110
Installing the Cisco NCS 2002 Door and Other Modules
NTP-L29 Installing the Standard Door of the NCS 2002 Shelf
