Connect the chassis to the office ground. For
detailed instructions on how to ground the
chassis, refer to the Electrostatic Discharge and
Grounding Guide for Cisco NCS 2000 Series .
•
NTP-L33 Installing the Power Module in the
NCS 2002 Shelf, on page 126
•
NTP-L35 Installing the Fan-Tray Assembly in
the NCS 2002 Shelf, on page 132
•
NTP-L35 Installing the Power and Ground to
the NCS 2002 Shelf, on page 76
•
NTP-L36 Attaching Wires to Timing, LAN, and
Craft Pin Connections in NCS 2002, on page
95
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Use the deep front panel when ONS-SC+-10G-C pluggables are installed on a NCS 2002 shelf.Note
Procedure
Step 1
Connect the ground strap cable:
a) Loosen the ground nut from the shelf (see the figure below).
b) Insert the lug of the ground strap cable and tighten the nut on the shelf to a torque value of 11.5 in-lb (1.3
N-m) (see the figure below).
Cisco NCS 2000 Series Hardware Installation Guide
116
Installing the Cisco NCS 2002 Door and Other Modules
NTP-L40 Installing the Deep-Front Panel of the NCS 2002 Shelf
