#2 Phillips Dynamometric screwdriver
•
Medium slot-head screwdriver
•
Small slot-head screwdriver
•
Screws: #12-24 x 3/4 pan-head Phillips
mounting screws (8)
•
Wing head screws (8)
•
Adapter plates
•
One air plenum kit (horizontal and vertical air
plenum)
Tools/Equipment
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
The airplenums for ANSI 23-inch configuration can be pre-assembled outside the cabinet and then installed
inside the cabinet. See DLP-L68 Installing Pre-assembled Air Plenums in ANSI 23-inch Configuration,
on page 154
Note
Cisco NCS 2000 Series Hardware Installation Guide
150
Installing the Air Flow Regulator
DLP-L66 Installing Air Plenum in NCS 2006 Shelf for ANSI 23-inch Configuration
