b) Install the wing head screws from the internal side of the horizontal plenum as shown in the figure below.
c) Tighten the screws to a torque value of 11.5 in-lb (1.3 N-m).
Figure 93: Installing the left vertical air plenum
Step 6
Install the vertical plenum to the right of the horizontal air plenum. Follow step 5a to step 5c.
Figure 94: Installing the right vertical air plenum
Cisco NCS 2000 Series Hardware Installation Guide
152
Installing the Air Flow Regulator
DLP-L66 Installing Air Plenum in NCS 2006 Shelf for ANSI 23-inch Configuration
