The NCS 2015 requires a minimum of 24.4 inches (619.76 mm) high vertical rack space. To ensure that
the mounting is secure, use eight mounting screws on each side of the shelf. A shelf should be mounted
at the bottom of the rack if it is the only unit in the rack.
Note
Procedure
Step 1
Verify that the proper fuse and alarm panel has been installed in the top mounting space. If a fuse and alarm
panel is not present, you must install one according to manufacturer instructions:
•
For a DC power supply, the fuse rating must not exceed 60 A.
•
For an AC power supply, the fuse rating must not exceed 20A. For North America, the branch circuit
protection must be rated 20A. The overcurrent/short circuit protection must be in accordance with local
and national electrical codes.
Step 2
Ensure that the shelf is mounted on the appropriate rack equipment:
•
23-inches (584.2 mm) or 19-inches (482.6 mm) for ANSI racks.
•
600 x 300-mm (23.6 x 11.8-inch) for ETSI racks.
Diagram 1 of the figure below shows the NCS 2015 DC shelf mounted on an ANSI rack in the middle position
using 19-inch mounting brackets.
Cisco NCS 2000 Series Hardware Installation Guide
320
Mounting the Cisco NCS 2015 Shelf
DLP-L72 Mounting NCS 2015 Shelf on a Rack (One Person)
