Step 5
T
ighten
the
screws
on
the
air
filter
assembly
to
secure
it
to
the
chassis.
See
the
figure
below
.
Figure 248: NCS 2015 DC Shelf with Replaced Air Filter
Screw
1
Step 6
Swing
the
door
closed
and
turn
the
knob
to
lock.
Stop.
Y
ou
have
completed
this
procedur
e.
Cisco NCS 2000 Series Hardware Installation Guide
451
Maintaining the NCS 2002, NCS 2006, and NCS 2015 Shelves
NTP-L58 Replacing the Air Filter of the NCS 2015 Shelf Assembly
478
480
