Left-hand assemblies
HP part number Part description Removal and installation
reference
Comments
1 F9A29-67008 Control Panel and support SFP
(T730)
Front Panel SFP F9A29-67008
on page 278
Includes plastic support with
power button and cables
2 F9A30-67047 NVM Backup PCA SV kit
3 CQ890-67044 Left side spittoon SV Left Spittoon on page 420 Includes gloves.
4 CQ890-67033 Encoder disk SV Encoder Disk on page 323 SV kit includes the brush. For
sensor parts, see Sensor Kit
on page 242
5 F9A30-67001 MAIN PCA SV Main PCA on page 311
6 CQ890-67089 5V Power Supply SV Power Supply on page 308
7 F9A30-67043 Control Panel and left trim MF
(T830)
Front Panel SFP F9A29-67008
on page 278
Includes plastic support with
power button and cables
236 Chapter 4 Parts and diagrams ENWW
