5 Removal and installation
Parts in alphabetical order Parts in removal order
Back Cover on page 275 Top window SFP F9A29-67007 on page 258
Bottom Cables F9A30-67034 on page 448 Front Cover on page 261
Bottom Platen F9A30-67042 on page 431 Right Cover MFP SV Kit F9A30-67011 on page 264
Bundle Board on page 406 Left Cover MFP SV Kit F9A30-67012 on page 268
Bundle Board FFC cable on page 408 Roll Cover on page 272
Calibration Surface F9A30-67027 on page 484 Back Cover on page 275
Calibration Slider on page 487 Front Panel SFP F9A29-67008 on page 278
Calibration Surface Gear Train F9A30-67028 on page 489 Central Cover on page 284
Carriage and Belt on page 344 Upper-Roll Paper Guide on page 289
Carriage Belt on page 351 Left Roll Support on page 292
Carriage Line Sensor on page 402 Right Roll Support on page 297
Carriage Motor on page 374 Encoder Strip on page 300
Central Cover on page 284 Printer NVM backup PCA on page 305
Cutter on page 379 Power Supply on page 308
Cutter Assembly on page 378 Main PCA on page 311
Cutter Bridge on page 380 Paper Motor on page 317
Cutter Door F9A30-67006 on page 378 Encoder PCA and Index on page 319
Cutter Guide on page 383 Encoder Disk on page 323
Diverter SV F9A30-67040 on page 516 Trailing Cable on page 326
Diverter bottom part F9A30-67062 on page 520 Service Station on page 334
Encoder Disk on page 323 Prime Pump on page 340
Encoder PCA and Index on page 319 Carriage and Belt on page 344
Encoder Strip on page 300 Carriage Belt on page 351
Front Cover on page 261 Right Gear Train Module on page 353
Front Panel and Left Trim F9A30-67043 on page 526 Starwheel Assembly on page 356
Front Panel SFP F9A29-67008 on page 278 Output Shaft on page 358
Front Window MFP SV Kit F9A30-67013 on page 502 Output Tray on page 365
ENWW 251
