HP DesignJet T730

Calibration Slider
IMPORTANT: Always change all three sliders.
Removal
1. Remove the Bottom Platen, see Bottom Platen F9A30-67042 on page 431.
2. Remove two screws.
3. Rotate the Calibration slider to unclip it from the 2 holes(only the middle module).
ENWW Calibration Slider 487
