HP DesignJet T730

Encoder PCA and Index
Removal
1. Switch o the printer and remove the power cable.
2. Remove the Front Cover, see Front Cover on page 261.
3. Remove the Cutter Door, see Cutter Door F9A30-67006 on page 378.
4. Remove the Left Cover, see Left Cover MFP SV Kit F9A30-67012 on page 268.
5. Remove the Main PCA, see Main PCA on page 311.
6. Remove one T-10 screw.
CAUTION: Be careful not to damage the Encoder Disk.
7. Release the PCA from the pin or locator.
ENWW Encoder PCA and Index 319
